Shale Shaker Screen
JRD specialized in various of shale shaker screen, flat screen and pyramd screen, the flat screen includings Hookstrip Flat Screen, Frame Flat Screen. Pyramd screen includings Hookstrip Pyramd Screen and Frame Pyramd Screen.
Application:
The shale shaker screen mainly used for shale shaker machine, vibrating screen machine.
JRD specialized in various of shale shaker screen, flat screen and pyramd screen, the flat screen includings Hookstrip Flat Screen, Frame Flat Screen. Pyramd screen includings Hookstrip Pyramd Screen and Frame Pyramd Screen.
Application:
The shale shaker screen mainly used for shale shaker machine, vibrating screen machine.
- Derick FlC500, Derick FlC2000.
- Brandt VSM300, Brandt Cobram
- Swacoo ALS, Swacoo Bem650
- Mongoose, Kemtron KTL48,Huayou.
Hookstrip Flat Screen are the series applied most widely at present. These products can be fit for all kinds of shale shakers that use the hookstrip flat screen. This screen panel is constructed with two or three stainless steel layers bonded to a steel support plank. Accessory rubber plugs may be inserted to the rips or tears of the screen. By doing this, we can cut down time and the production cost. We can supply hookstrip flat screens with mesh sizes ranging from 12 to 275.
The Frame Flat Screen are made from metal. The wire cloth is rigidly bonded to a perforated metal panel which will prolong the screen life.
Material: stainless steel wire, low carbon galvanized.；Weaving and characteristics: crimp before welding.Uses: used in coal, mine, water etc. profession.
Frame Pyramd Screen
The effective area is 125% to 150% of flat screens. Without changing the construction of shakers, the using of the frame pyramid screens can improve the quality of drilling fluid and increase the production.
Hookstrip pyramd screens
It is the replacement products of flat screens. The effective area is 125% to 150% of flat screens. Without changing the construction of shakers, the using of the pyramd screens can improve the quality of drilling fluid and increase the production.
shale shaker screen hookstrip pyramd screen frame flat screen derick flat screen
shale shaker screen hookstrip pyramd screen frame flat screen derick flat screen
| Derick Flat Screen | PWP | 40mesh/20meshx700x1050 |
| 48-30D | 80mesh/20meshx700x1050 | |
| 120mesh/30meshx700x1050 | ||
| 160mesh/40meshx700x1050 | ||
| 40mesh-200mesh for this type as above | ||
| Derick Pyramd Screen | PMD | 20mesh/12meshx700x1050 |
| 48-30D | 40mesh/18mesh/12meshx700x1050 | |
| 100mesh/40mesh/20meshx700x1050 | ||
| 160mesh/60mesh/20meshx700x1050 | ||
| 200mesh/60mesh/20meshx700x1050 | ||
| 20mesh-200mesh for this type as above | ||
| KaiTeLong three tier conglutination Screen | 40mesh/20mesh/12meshx715x1215 | |
| 80mesh/40mesh/12meshx715x1215 | ||
| 120mesh/40mesh/20meshx715x1215 | ||
| 180mesh/60mesh/20meshx715x1215 | ||
| 20mesh-200mesh for this type as above | ||
| Swacoo Screen Mesh | 40mesh/12meshx900x1146 | |
| 80mesh/20meshx900x1146 | ||
| 140mesh/20meshx900x1146 | ||
| 20mesh-160mesh for this type as above | ||
| HuaYou vibrating sieving mesh | NS-115/2 | 60mesh/20meshx1150x1000 |
| 100mesh/20meshx1150x1000 | ||
